Dual-Mode Heterogeneous Detection System FC-815

Product overview

The dual-mode heterogeneous detection system can test the main performance parameters of the dual-mode heterogeneous local communication unit. According to the relevant standards and technical specifications of the grid company, it performs a series of unified technical specifications and communication protocol tests for the network link and its node units. So as to implement systematic indicator detection and evaluation. It can effectively improve the stability, reliability and scalability of the power user information collection system, and is of great significance to the realization of the goal of "full coverage, full collection, and full cost control".

Functional features

  • Features of dual-mode heterogeneous detection system:
  • 1.Test mode using virtual tooling;
  • 2.Provide a standardized measurement environment;
  • 3.Can test the radio frequency performance of dual-mode heterogeneous local communication unit modules at the same time;
  • 4.Can conduct agreement consistency analysis;
  • 5.Can carry out carrier electric performance test;
  • 6.Simulate the field communication environment of 1-7 level routing;
  • 7.Test and evaluate network services, such as meter reading, stepped tariff, etc.;
  • 8.Evaluate network performance, such as transmission delay, packet loss, etc.;
  • 9.Verify the stability of the communication protocol.
  • Technical ParametersView details

    • Three-phase AC purification regulated power supply: 10KVA
    • Industrial computer:
    • CPU type: Intel Core i7 series;
    • CPU frequency: ≥2.8GHz;
    • Memory type: DDR3;
    • Memory capacity: ≥8GB;
    • Hard disk capacity: ≥1TB;
    • Hard disk speed: ≥7200r;
    • Graphics card: dual DVI output.
    • Isolation transformer: 10KVA
    • DC power supply: 0~30V, 0.5% accuracy
    • Standard signal source
    •         Operating frequency: 9kHz~3.0GHz.
    •         Baseband generator mode: Waveform Playback and Real-Time.
    •         Software support, analog I/Q input, I/Q waveform, multi-tone and NPR, noise (AWGN), phase noise reduction, pulse, burst generator, AM, FM, PM, ASK, FSK, MSK, MATLAB , PSK, QAM.
    •         Waveform playback memory: 512 Msa
    • Spectrum Analyzer
    •         Operating frequency: 10Hz~3.6GHz.
    • Maximum analysis bandwidth: 40MHz.
